Whirlpool Washer Error Code F08 (Won’t Heat Water)

F08 means the washer isn’t heating water to the expected temperature, usually a failed heating element or tripped safety thermostat.

Risk: Moderate

Meaning

F08 appears when water temperature doesn’t rise as expected during the cycle. A blown heating element or a tripped safety thermostat is the usual cause.

The heating element typically fails from age or from scale coating the coil heavily enough to insulate it from the water around it. The safety thermostat is a separate, cheaper part that trips as a protective measure if the element overheats, so it’s worth testing before assuming the element itself needs replacing. Either part is usually reachable from behind the washer’s rear panel without pulling the whole machine apart.

The information provided here is a diagnostic aid and does not replace the intervention of a qualified professional.

Possible causes

No cause is certain until it has been checked on the appliance.

Likely Heating element burned out
Possible Safety thermostat tripped
Possible Scale buildup interfering with the temperature reading

Tools needed

Multimeter
Screwdriver
Needle-nose pliers
Descaler

First checks

Test the heating element for continuity with a multimeter.
Check the safety thermostat and reset it if needed.
Descale the tub if the washer hasn't been maintained in a while.

Step-by-step diagnosis

Unplug the washer and wait for the water to cool.
Remove the rear panel to reach the heating element under the tub.
Photograph the connections before pulling the terminals. They are not interchangeable.
Measure resistance across the two element terminals. A washer element usually falls between 20 and 40 ohms. Infinite means it has gone open circuit.
Now measure between one terminal and the metal chassis. Any low reading means the element is leaking to earth, and it has to be replaced regardless of what the first measurement said.
Check the safety thermostat for continuity when cold. If it does not pass, it has tripped, and the reason it tripped matters more than the thermostat itself.

What not to do

Running repeated hot cycles hoping the fault clears on its own.
Replacing the heating element before checking the safety thermostat, which is the cheaper and more common failure of the two.

When to stop

A confirmed earth leak, or a breaker that trips when you restore power. That is an insulation fault and it belongs to a professional.
Element and thermostat both measure correctly but F08 persists, which puts the fault on the board.

An error code varies by brand

The same code can have a different meaning depending on the brand and model. Always check your appliance's manual before acting.

Related guides

When to call a professional

If the simple checks turned up nothing, if the repair involves electricity, gas, or the sealed refrigerant system, or if you have any doubt at all: stop there and hand the appliance over to a qualified technician.
